Vehicle-Mounted
Flexible LED Screen
Engineered for mobile advertising on car roofs and rear windows. Custom power units run off vehicle batteries, backed by a shockproof frame that dampens road vibrations.
- ✓ 12V/24V DC vehicle grid compliance protects car alternators
- ✓ Anti-vibration structural casing protects pixel solder joints
- ✓ 4G/5G cloud controller updates ads and tracks location via GPS
On-The-Road Advertising
Built to deliver clear, bright digital ads while moving at highway speeds.
Vehicle Grid Smart Power
Internal converters isolate the display from vehicle voltage spikes. Features auto-shutoff when the car battery drops below safety levels.
Vibration Protection
Thick structural silicone pads cushion the LEDs. Meets high automotive transit standards for highway and off-road driving.
Geofenced Scheduling
Our cloud platform syncs with GPS tracking, allowing you to update ads and trigger different campaigns based on the vehicle's location.
Technical Data
| Available Pixel Pitches | P4.0mm, P5.0mm flexible module options |
|---|---|
| Cabinet Material | Polycarbonate chassis with anti-UV casing |
| Peak Brightness | 4,000 nits (Adjusts via vehicle light sensor) |
| Input Voltage | 9V - 36V DC (Compatible with cars, buses, and trucks) |
| Vibration Rating | QC/T 413 automotive standard compliant |
| Refresh Rate | 1,920 Hz (Ensures flicker-free display on mobile cameras) |
| Connectivity | 4G / 5G / Wi-Fi cloud interface with GPS routing |
| Protection Rating | IP65 (Full dustproofing and rain waterproofing) |
Frequently Asked Questions
Can I power this screen directly from the car battery?
Yes. Our screens include intelligent DC-to-DC converters that wire into 12V or 24V car systems, preventing power surges from damaging the display.
Does the screen survive road bumps and high speeds?
Yes. The display chassis uses anti-vibration rubber gaskets and silicone glue backings, keeping the panel solder joints safe at highway speeds.
How do I change the advertising content?
You can update images and videos remotely over 4G/5G networks using our mobile app or a web browser, allowing you to manage campaigns on the go.
Can the screen trigger ads based on the vehicle's location?
Yes. The built-in GPS module supports geofencing, letting you display neighborhood-specific ads as the vehicle drives through different parts of the city.
Request Mobile Ad Spec
Send us your vehicle model, mounting preference (roof, window, or rear), and fleet size for a customized proposal.
