Touring Event
Rental Panels
Lightweight, modular LED panels designed for rapid stage assembly. Built to survive road transport and deliver high-contrast visuals under bright spotlights.
- ✓ Tool-less fast-lock system allows rapid assembly by one person
- ✓ Adjustable side angle brackets form curves from -10° to +10°
- ✓ Built-in corner shields protect fragile edge pixels during setup
High-Speed Stage Assembly
Engineered to minimize setup times and protect panels from handling damage on the road.
Quick-Lock Brackets
Heavy-duty handles and automatic lock alignment pins let a single stagehand build, align, and lock modules securely without tools.
Interlocking Curve
Angle-adjusting side plates lock into place with pins. Build concave backdrops or convex columns to fit creative stage layouts.
Corner Protectors
Spring-loaded guards cover panel edges, flipping back automatically when locked together to keep pixels safe from bumps.
Technical Data
| Available Pixel Pitches | P2.6mm, P2.97mm (Indoor) / P3.91mm (Outdoor/Dual-Use) |
|---|---|
| Cabinet Material | Die-cast lightweight structural aluminum |
| Cabinet Dimensions | 500mm x 500mm / 500mm x 1000mm standard sizing |
| Peak Brightness | 1,500 nits (Indoor) / 5,000 nits (Outdoor) |
| Refresh Rate | 3,840 Hz - 7,680 Hz (High refresh options for camera sync) |
| Weight per Cabinet | 6.8 kg (500x500mm aluminum enclosure) |
| Curving Angles | -10°, -5°, 0°, +5°, +10° index-pinned adjustment |
| Ingress Protection | IP65 Front / IP54 Rear (Dual-use outdoor compliant) |
Frequently Asked Questions
How fast can these panels be assembled?
Thanks to the quick-lock brackets, a two-person team can build a standard 10m x 3m backdrop screen, align the panels, and secure the power cabling in under 90 minutes.
Can I build curved screens with this model?
Yes. The side locking plates feature a pin system that adjusts in 5-degree steps, letting you build concave or convex curves ranging from -10 to +10 degrees.
Are these panels safe for outdoor events in the rain?
Yes. The outdoor P3.91 version features IP65 front protection and waterproof power/signal connectors, allowing the display to run safely in rainy weather.
What accessories are included in the flight cases?
Each case contains 8 panels, hanging bars, floor-stacking brackets, power jumper leads, signal cables, and a toolkit with spare mask covers and receiver cards.
Request Rental Panel Quote
Send us your project dimensions and staging requirements to get a customized system design and budget proposal.
